652 wide x 456 high (pixel) Shaded Perspective Image (.DXF surfaces)

P120FB03: repeat at 4:1 with target moved midway (90 mm) between lens and SIRTF focal plane. Target shifted from white toward green quadrant of target. Note that the Target is not inverted. The central fiducials can just be distinguished (cyan). The cyan fiducial is 1 mm x 0.05 mm.
