652 wide x 456 high (pixel) Ray Traced Perspective Image (.DXF surfaces)

P120FB10: Rendering is 4:1 for faster display at lower resolution. Move Target center to former corner of green quadrant. Turn Target On for Perspective Autovision Raytrace Rendering. Target is centered in FOV! Note Colored fiducial pattern at center of red, white, blue, green target center quadrants. The image is inverted from the target. The Magenta, yellow, gray, cyan fiducials are 0.05 mm wide by 1 mm long. The horizontal fiducials are truncated by edges.
